DECCAN 5HP 20 STAGE 150MM BORE WELL SUB PUMPSET
₹46,603.00
KEY FEATURES
Motor portion covered with corrosive resistance Stainless steel (SS 304) shell
More durability & hygiene
High operating efficiency
Extremely hardwearing water lubricated bearing
Designed for wide voltage operation
Specially designed thrust bearing to withstand high axial thrust load
Also use this product 150mm bore wells & Open wells
Product description
Model | DR60/20 |
Power Range | 3.7 kW / 5 HP |
Voltage range | Three Phase 380 – 440 V |
Connection | STAR (DOL) |
Head Range | 60 – 160 m |
Flow range | 175 - 50 lpm |
Delivery size | 50 mm |
Warranty | 2 Yrs |
Intermidate piece | CI-FG-200 |
Casing | CI-FG-200 |
Impeller | SS 304 & SS 410 |
NRV Housing | CI-FG-200 |
Tie Rod | MS |
Shaft sleeve | SS 410 |
Pump shaft | SS 410 |
Motor Base | CI-FG-200 |
Upper Housing | CI-FG-200 |
Motor Body | SS 304 Fabricate with SI Stamping |
Winding | Insulated copper |
Journel bushes | LTB-4 |
Lower housing | CI-FG-200 |
Rotor with shaft | Copper Rotor with SS 420 Shaft |
Thrust bearing | Carbon / SS 420 |
